CT100 (MOHR Engineering) Features and Specifications *
The MOHR CT100 is a high-precision Time Domain Reflectometer (TDR) cable tester designed for advanced diagnostics and maintenance of microwave, RF, and digital communication systems. Engineered with state-of-the-art technology, it offers industry-leading fault sensitivity, spatial resolution, and measurement accuracy, making it an essential tool for professionals dealing with cable infrastructure in industries such as aerospace, telecommunications, and power distribution. It is its ultrawideband step-pulse architecture combined with 16-bit digital sampling, allowing it to detect even the smallest cable faults before they become critical. The device delivers a system risetime as low as 60 picoseconds (ps), ensuring high-speed and precise signal transmission for detecting discontinuities and signal integrity issues. Its ability to acquire up to 500 waveforms per second further enhances its capability to capture and analyze transient faults that might otherwise go unnoticed. A defining characteristic of this unit is its unparalleled spatial and cursor resolution. With a cursor resolution of 75 microns (0.003 inches), it allows users to pinpoint the exact location of cable defects with a level of accuracy that surpasses most competing TDR and Frequency Domain Reflectometry (FDR) instruments. Its spatial resolution enables the identification of faults, interconnects, and PCB features separated by as little as 9 mm (CT100HF) or 14 mm (CT100). This precision is critical for industries where minimal signal disruption is paramount. Another feature of the CT100 is its ability to conduct high-resolution cable scanning. The device can scan entire cables or specific sections with exceptional detail, capturing millions of data points. This data can be stored in its 2 GB internal memory and later analyzed or compared using the included CT Viewer™ TDR analysis software. This software facilitates waveform translation and rescaling, allowing for in-depth comparisons between historical and real-time scans, enhancing diagnostic efficiency.
Connectivity and remote access capabilities are also key advantages of the MOHR CT100. It features USB host/client ports and a 10/100 Mb Ethernet connection, allowing seamless data transfer and integration with external devices such as PCs, USB drives, keyboards, and barcode readers. Additionally, the unit supports live streaming and remote control via LAN, WAN, or the internet, providing real-time monitoring and control from virtually anywhere using CT Viewer™. These advanced connectivity features make the CT100 an excellent choice for field engineers and technicians who require remote access to diagnostics and data. Designed with user ergonomics in mind, the CT100 is lightweight, portable, and rugged, making it well-suited for demanding environments. The device features a bright, daylight-readable color TFT-LCD screen, ensuring visibility even in outdoor or low-light conditions. It operates on an internal NiMH battery with an extended life of over eight hours under typical usage. External battery packs are also available for unlimited operation, making it highly adaptable for long-duration fieldwork. The MOHR CT100 supports a wide range of applications, including telecommunications, aerospace, marine, and industrial sectors. It is particularly effective in fault detection and maintenance of CATV, power, and telephony cables, as well as wireless infrastructure and PC board impedance testing. It is also utilized in specialized applications such as geophysics and soil moisture analysis, demonstrating its versatility beyond traditional cable testing. Technically, the CT100 offers a broad range of measurement and processing capabilities. It features automated measurement functions, including time-to-fault, distance-to-fault, and return loss calculations, providing users with essential diagnostics in real time. Additionally, the unit offers waveform processing functions such as averaging, subtraction, Fast Fourier Transform (FFT), and one-port S-parameter estimation (S11), making it a powerful tool for in-depth signal analysis. From a power perspective, the CT100 operates on both AC and battery power, making it highly flexible for various working conditions. The device includes an AC adapter compatible with 110/220V power sources, while its rapid-charging internal battery ensures minimal downtime. This is also designed to withstand a range of environmental conditions, with an operating temperature range of 0ºC to 50ºC and a non-operating range of -20ºC to 60ºC, further proving its robustness in diverse field conditions. Standard accessories included with the CT100 consist of a 50Ω precision test cable, a set of BNC/SMA terminators, and a soft-sided carrying case for convenient transportation. Optional accessories, such as external battery packs, hard carrying cases, and impedance-matching adapters, expand its functionality and adaptability for various testing environments.
MOHR CT100 is a highly sophisticated TDR cable tester that excels in precision, speed, and versatility. With its industry-leading fault detection capabilities, superior spatial resolution, and advanced connectivity, it is an indispensable tool for professionals in RF, microwave, and digital communication fields. The device’s combination of high-performance diagnostics, user-friendly design, and remote accessibility ensures that it remains a top choice for engineers and technicians looking to maintain the highest standards in cable testing and fault analysis.
The MOHR CT100 price and features make it a very attractive option comparing to similar TDR cable testers available on the market.
